The Surgical Panel SP2-24-49 with two integrated monitors as well as build-in IT and video management components is a digital image viewing system, designed for use in the operating room. Integrated into the hospital’s IT structure, it supports various workflows. The SP2-24-49 forms a space-saving combination of HIS and PACS station. Different applications are covered by just one device.

A 26-inch wide screen surgical monitor with full HD display that faithfully reproduces surgical images.

• 26-inch LCD monitor with full HD resolution (1920 x 1080 pixels)
• Powerful LED backlight with 700 cd/m² luminance for optimal viewing in bright operating rooms
• High IP rating and fanless design ideal for maintaining a sterilized OR environment
• Sleek design with fully-flat protective panel and rounded corners for comfort and safety in the operating room

A 26-inch wide screen surgical monitor with full HD display and three screen support.

• 26-inch LCD monitor with full HD resolution (1920 x 1080 pixels)
• Powerful LED backlight with 700 cd/m² luminance for optimal viewing in bright operating rooms
• Smart Resolution with Sparse Coding (S.R.S.C.) for high definition images
• Up to three video sources can be displayed simultaneously
• High IP rating and fanless design ideal for maintaining a sterilized OR environment

The TID0102 splits the DVI signal from the LMM0804 into two configurable signals. The TID0102-HDL provides additional HDL transmission technology to enable video transmission via traditional CAT cables at a distance of up to 70 m.

• TID0102-DVI or TID0102-HDL model available
• Flexible, configurable video output
• Variable EDID (Extended Display Identification Data) handling
• Automatic monitor detection at output

The PDC0100 converts analog video signals into digital DVI format. This allows existing analog systems and devices that use digital signals to be combined. With a range of accessories and high interconnectivity, the converter allows maximum flexibility for integration into existing systems.

The Large Monitor Manager LMM0804 enables digital and analog images from various sources to be arranged flexibly on large-format or multiple monitors. The LMM0804 has been designed for use in operating rooms, where an extremely flexible image display is required during surgery. At the same time, the image content for each individual unit can be defined separately.

• Small and compact size allows easy installation in existing systems.
• Up to 8 signal sources can be displayed simultaneously on a maximum of 5 connected monitors.
• The monitors can be connected over a distance of up to 36 m.
• Image is available within 4 secondes after system reboot.
• Maximum image latency of one frame (input to output) provides almost real-time image).

Ultra-High Definition camera system with fully integrated triaxial mount for capturing surgical proceedings.

• 4K ultra high definition resolution at 60p
• 30x optical zoom for clear, close-up images
• Integrated triaxial camera mount with pan, tilt, and roll
• Intuitive camera movement for simple operation
• Single cable connection between camera head and CCU
• Smooth positioning even under high zoom
• Attach to ceiling arms for obstruction-free video

This 49” widescreen monitor is ideally suited for viewing medical images under OR conditions. Numerous input and output signals, image combination capabilities, and gamma models pre-calibrated at the factory enable its use within the widest range of applications. With its fan-free design and water-tight, easy to clean front, the monitor is perfectly suited for sterile hospital environments.

• Five factory-set look up tables according to DICOM and Gamma 2.2 for optimal image reproduction
• Fast adaptation to various environments and procedures
• Numerous video inputs and outputs for increased connectivity
• Flexible image arrangement thanks to the Picture-in-Picture (PiP) and Picture-at-Picture (PaP) functions
• Fully automated brightness stability using ISS (Integrated Stability System)

The DVI Transmission Link TDL3600 and TDL2300 enable data transmission of high-quality video data of up to 36 or 23 meters with no quality loss. Transmitting the data over an Ethernet cable allows robust handling and simple setup, and the cables can be easily run through small conduits and holes.

With TIP0210-DVI, image and video data, as well as control signals, can be transmitted with zero latency or loss in a 10 Gbit network. As a result, a flexible video routing can be realized using standardized, forwardlooking network technology.

• Uncompressed, loss-free data transmission of 10 Gbit/s
• Transmission with zero latency, for better hand-eye coordination
• One device per software can be used as a decoder and encoder
• Up to two video links per device can be processed
• Multiple views on a monitor possible through one signal
• Passive cooling

A 32-inch widescreen surgical monitor with 4K UHD (3840 x 2160 pixels) resolution and high brightness.

Smart Resolution with Sparse Coding (S.R.S.C.) for high definition images
DisplayPort 1.2, 12G-SDI and HDMI for easy connection
12G-SDI (BNC) for long-distance connectivity
Optical bonding for reduced reflections, high durability and condensation prevention
High IP rating for maintaining a sterilized OR environment
