The Large Monitor Manager LMM0804 enables digital and analog images from various sources to be arranged flexibly on large-format or multiple monitors. The LMM0804 has been designed for use in operating rooms, where an extremely flexible image display is required during surgery. At the same time, the image content for each individual unit can be defined separately.

• Small and compact size allows easy installation in existing systems.
• Up to 8 signal sources can be displayed simultaneously on a maximum of 5 connected monitors.
• The monitors can be connected over a distance of up to 36 m.
• Image is available within 4 secondes after system reboot.
• Maximum image latency of one frame (input to output) provides almost real-time image).

A 26-inch wide screen surgical monitor with full HD display that faithfully reproduces surgical images.

• 26-inch LCD monitor with full HD resolution (1920 x 1080 pixels)
• Powerful LED backlight with 700 cd/m² luminance for optimal viewing in bright operating rooms
• High IP rating and fanless design ideal for maintaining a sterilized OR environment
• Sleek design with fully-flat protective panel and rounded corners for comfort and safety in the operating room

This 49” widescreen monitor is ideally suited for viewing medical images under OR conditions. Numerous input and output signals, image combination capabilities, and gamma models pre-calibrated at the factory enable its use within the widest range of applications. With its fan-free design and water-tight, easy to clean front, the monitor is perfectly suited for sterile hospital environments.

• Five factory-set look up tables according to DICOM and Gamma 2.2 for optimal image reproduction
• Fast adaptation to various environments and procedures
• Numerous video inputs and outputs for increased connectivity
• Flexible image arrangement thanks to the Picture-in-Picture (PiP) and Picture-at-Picture (PaP) functions
• Fully automated brightness stability using ISS (Integrated Stability System)

With TIP0210-DVI, image and video data, as well as control signals, can be transmitted with zero latency or loss in a 10 Gbit network. As a result, a flexible video routing can be realized using standardized, forwardlooking network technology.

• Uncompressed, loss-free data transmission of 10 Gbit/s
• Transmission with zero latency, for better hand-eye coordination
• One device per software can be used as a decoder and encoder
• Up to two video links per device can be processed
• Multiple views on a monitor possible through one signal
• Passive cooling

With TIP0410-HDMI, image and video data, as well as control signals, can be transmitted with zero latency or loss in a 10 Gbit network. As a result, a flexible video routing can be realized using standardized, forwardlooking network technology.

• Uncompressed, loss-free data transmission of 10 Gbit/s
• Transmission with zero latency, for better hand-eye coordination
• One device can be used as a decoder and encoder
• Up to two video links per device can be processed
• Multiple views on a monitor possible through one signal
• Passive cooling

This Full HD widescreen monitor is ideally suited for viewing images in surgical environments. With its modular design, the EX271W is streamlined as a future-safe platform for evolving environments and further integration into a wider system.

• 27-inch LCD module with 1080p (Full HD) resolution (1920 x 1080 pixels).
• Powerful LED backlight with over 500 cd/m² luminance for an optimal presentation of critical images.
• 5 factory calibrated look-up tables for quick and easy adaptation to diverse application and viewing environments.
• Modular concept for targeted integration into current and future systems.
• Sleek, encapsulated design with laminated safety glass and an unsurpassed IP rating ideally suited to the OR environment.

A 31.5-inch wide screen surgical monitor with full HD display that faithfully reproduces surgical images.

• 31.5-inch LCD monitor with full HD resolution (1920 x 1080 pixels)
• Powerful LED backlight with 650 cd/m² luminance for optimal viewing in bright operating rooms
• High IP rating and fanless design ideal for maintaining a sterilized OR environment
• Sleek design with fully-flat protective glass and rounded corners for comfort and safety in the operating room

By utilizing PDS0800-HD, signals coming from LMM56800 or LMM0802 are repeated and doubled to connect two 8 megapixel monitors. The HD output generates a downscaled representation of the content displayed on the large screen.

A 26-inch wide screen surgical monitor with full HD display and three screen support.

• 26-inch LCD monitor with full HD resolution (1920 x 1080 pixels)
• Powerful LED backlight with 700 cd/m² luminance for optimal viewing in bright operating rooms
• Smart Resolution with Sparse Coding (S.R.S.C.) for high definition images
• Up to three video sources can be displayed simultaneously
• High IP rating and fanless design ideal for maintaining a sterilized OR environment

Faithfully reproduce stereoscopic images with this 31.5-inch widescreen 3D surgical monitor.

• 31.5-inch LCD monitor with full HD resolution (1920 x 1080 pixels)
• Powerful LED backlight with 650 cd/m² luminance for optimal viewing in bright operating rooms
• High IP rating and fanless design ideal for maintaining a sterilized OR environment
• Optical bonding for reduced reflections, high durability and condensation prevention
• Battery-free, fogless glasses for clearly and comfortably viewing 3D images
• Sleek design with fully-flat protective glass and rounded corners for comfort and safety in the operating room

57.5-inch monitor with 4K UHD resolution for use in Hybrid ORs and interventional radiology.

• Ideal for displaying medical images for angiography, cardiology and radiology
• Monitor calibration during production according to DICOM Part 14
• Integrated stability system for maintaining the calibration
• Designed for cost effective videomanagement solutions

58-inch widescreen surgical monitor with 4K UHD display that faithfully reproduces surgical images.

• 58-inch LCD monitor with 4K UHD (3840 x 2160 pixels) resolution
• Picture reproduction without delay and flicker
• DisplayPort 1.2 for easy connection
• 12G-SDI (BNC) for long-distance connectivity
• High IP rating ideal for maintaining a sterilized operating room environment
