CuratOR Surgical Panel SP2-24-554K

Τιμή:

The Surgical Panel SP2-24-554K with two integrated monitors as well as build-in IT and video management components is a digital image viewing system, designed for use in the operating room. Integrated into the hospital’s IT structure, it supports various workflows. The SP2-24-554K serves as space-saving combination of work and viewing stations. Different applications are covered by just one device.

Built-in 24” and 55” monitor and touchscreen options
Workstation for image viewing and documentation
Space-saving wall mounting
High ease of service and maintanance
Flexible choice of material, configuration and accessories
Completely sealed within the OR and disinfectible

Τιμή:


Intuitive Touch Operation

Every CuratOR Surgical Panels can be equipped with a touchscreen to facilitate intuitive operation of software in the OR. They are easily operated while wearing gloves for use in sterile environments.

Customized Housing

The housing dimensions can be customized along with the combination of the powdered stainless steel and glass housing materials. Customers can select colors from the RAL palette range to suit the OR color scheme.

Optimized View Through Simple LUT Switching

Every 4K Surgical Panel is equipped with an easy-access LUT switch as standard. One of five predefined lookup tables can be selected at the simple press of a button. This allows operators to display various medical images and videos under optimal viewing settings.

Wide Ranging Monitor Options

The Surgical Panel are available in a wide range of screen diagonals for flexibly meeting local application requirements. The option to combine a viewing unit with a 24“ Full HD HIS workstation also offers a full viewing environment while saving on space.

Flexible Integrated Video Management VMbasic

A modular interior design enables customer-specific configuration. Every 4K Surgical Panel can be optionally equipped with the video management function VMbasic. Easily switch between video signals connected internally or on the front at the simple press of a button. Two further buttons allow the selection of the preset layouts and the selection of the active window.

OR Integration and Cleanability

With its flat surface, the Surgical Panel can be completely sealed in the front and integrated in the OR wall, ensuring safety and simple cleaning and disinfection procedures. With intelligent heat distribution over the front surface, the units do not require specialized ventilation systems.

Flexible Mounting Options

The device is designed for both surface or flush-mounted installation to allow easy fit into the local architectural preferences and physical circumstances on site.

Accessories and Connectivity

Surgical Panel have front USB ports as standard for connecting peripheral devices. There is also the option of integrating additional interfaces on the front frame. These can be individually connected to the inputs available in video management.

Easy Maintenance and Service

The trunk design allows easy access to the device without complicated disassembly or tools. With its unique locking system, no screws need to be taken out, making maintenance procedures on the installed components simple and efficient.

Specifications

General

Model Variations SP2-24-554K: without touchscreen
SP2-24T-554K: with touchscreen (24″)
SP2-24-554KT: with touchscreen (55″)
SP2-24T-554KT: with touchscreen (24″, 55″)
Certifications & Standards (Please contact EIZO for the latest information) CE, IEC/EN 62368-1, IEC/EN 60601-1-2, RoHS, WEEE

Housing

Material Powder-coated stainless steel
Front Combination of stainless steel and anti-reflective safety glass (ESG)
Color Available in every RAL color
Mounting Options Suitable for flush mounting or surface mounting

Panel 24″

Size 24″ (60.5 cm, 16:9 apect ratio)
Type Color TFT LCD Panel with DICOM Preset
Native Resolution 1920 × 1080 (Full HD)
Display Colors 16.77 million colors
Pixel Pitch 0.275 mm x 0.275 mm
Brightness (typical) 350 cd/m²
Contrast Ratio (typical) 1000:1
Viewing Angles (H / V, typical) 178º, 178º
Response Time (typical) 14 ms (Gray-to-Gray)
Backlight LED
Signal Inputs DisplayPort 1.2 x 2, DVI-D single link, HDMI 1.4, HDMI 2.0 x 2, VGA

Panel 55″ (4K)

Size 55″ (138.8 cm, 16:9 aspect ratio)
Type Color TFT LCD Panel with DICOM Preset
Native Resolution 3840 × 2160 (UHD)
Display Colors 1.07 billion colors
Pixel Pitch 0.315 mm x 0.315 mm
Brightness (typical) 700 cd/m²
Contrast Ratio (typical) 1100:1
Viewing Angles (H / V, typical) 178º, 178º
Response Time (typical) 8.0 ms (Gray-to-Gray)
Backlight LED
Signal Inputs DisplayPort 1.2 x 2, DVI-D single link, HDMI 1.4, HDMI 2.0 x 2, VGA

Hardware & Software Components

Touchscreen Projected capacitive, multi-touch (SP2-24T-554K, SP2-24-554KT, SP2-24T-554KT only)
IT Components INTEL® Core™ i5 processor – 3.x GHz, INTEL® Chipset, 6 MB L3 Cache, 8 GB DDR3 RAM (extendable), SATA HDD or SATA SSD, LAN RJ 45 – 10/100/1000 Base TX
Operating System MS Windows 10 Pro

Interface Specifications

Keyboard / Mouse Anti-microbial medical silicone keyboard with integrated mouse storage (foldable), silicone mouse (visual 5 keys, laser mouse /IP65)
USB Ports USB 2.0 / 3.0 x 2 (front side)
Push Buttons Main switch (front side)
System switch (front side)
LUT button (front side)VMbasic (optional):
Video input button (front side): DisplayPort 1.2, HDMI 2.0, HDMI 1.4, VGA, DVI Single Link
Layout button (front side): PiP, PaP, LR, TB, Quadsplit, Single
Select button (front side)

Power

Power Consumption 300 W (maximum)
Power Requirements 100 – 240 V / 50 – 60 Hz / 4 – 2 A
Thermal Load 1080.0 kJ/h

Physical Specifications

Net Weight 72 kg
Dimensions (mm) Niche (W x H x D): 2157.8 x 1018.4 x 140
Device (W x H x D): 2147.8 x 1008.4 x 120

Dimensions
