The constantly growing number of medical devices and equipment used in the OR is a major challenge for OR and nursing staff. This is because, even in stressful situations, they have to be able to operate the equipment without making an error. Different user interfaces and systems that are not compatible with one another sometimes force the OR team into using awkward workflows.

With CuratOR Caliop, EIZO has developed an integration software that centralizes key OR-workflows on a single platform.

• Simple and intuitive menu navigation
• Manufacturer-independent integration
• Designed for use with mouse and touchscreen as well as remotely (foot switch / endoscope head buttons)
• Only one user interface is necessary
• Modules can be added on and additional elements can be purchased later
• Saves time and money
• Uncomplicated administration

The PDC0100 converts analog video signals into digital DVI format. This allows existing analog systems and devices that use digital signals to be combined. With a range of accessories and high interconnectivity, the converter allows maximum flexibility for integration into existing systems.

Display high-definition images on this 31.1-inch 4K UHD surgical monitor.

• 31.1-inch LCD monitor with 4K UHD (3840 x 2160 pixels) resolution
• Smart Resolution with Sparse Coding (S.R.S.C.) for high definition images
• DisplayPort 1.2 for easy connection and 3G-SDI (BNC) for long-distance connectivity
• Sleek design with fully-flat protective glass and rounded corners for comfort and safety in the operating room
• High IP rating ideal for maintaining a sterilized operating room environment

The LMM0802 is a Large Monitor Manager for 2, 4 and 8 megapixel monitors. It gathers various video inputs and display them on the large screen. Different layouts can be arranged according to user preferences and working situation. This simplifies the surgeon’s individual workflow.

• Small dimensions allow easy installation in existing systems.
• Single and Dual Workspace supported.
• Video signal is valid at the output within 4 seconds after switching on.
• Long product life cycle by using ling term available parts.
• Maximum image latency of one frame (input to output).
• Switch time between layouts sets less than 0.5 second with flicker-free picture.
• Scaler output allows distribution of arranged image to HD monitor or recording system.

The TID0102 splits the DVI signal from the LMM0804 into two configurable signals. The TID0102-HDL provides additional HDL transmission technology to enable video transmission via traditional CAT cables at a distance of up to 70 m.

• TID0102-DVI or TID0102-HDL model available
• Flexible, configurable video output
• Variable EDID (Extended Display Identification Data) handling
• Automatic monitor detection at output

Faithfully reproduce 4K UHD stereoscopic images with this 31.1-inch widescreen 3D surgical monitor.

• 31.1-inch LCD monitor with 4K UHD (3840 x 2160 pixels) resolution
• Smart Resolution with Sparse Coding (S.R.S.C.) for high definition images
• DisplayPort 1.2 for easy connection and 12G-SDI (BNC) for long-distance connectivity
• High IP rating ideal for maintaining a sterilized operating room environment
• Optical bonding for reduced reflections, high durability and condensation prevention
• Battery-free, fogless glasses for clearly and comfortably viewing 3D images

The DVI Transmission Link TDL3600 and TDL2300 enable data transmission of high-quality video data of up to 36 or 23 meters with no quality loss. Transmitting the data over an Ethernet cable allows robust handling and simple setup, and the cables can be easily run through small conduits and holes.

A 27-inch widescreen surgical monitor with full HD display that faithfully reproduces surgical images.

• 27-inch LCD monitor with full HD resolution (1920 x 1080 pixels)
• Powerful LED backlight with 900 cd/m² luminance for optimal viewing in bright operating rooms
• High IP rating and fanless design ideal for maintaining a sterilized OR environment
• Sleek design with fully-flat protective glass and rounded corners for comfort and safety in the operating room

58-inch widescreen surgical monitor with 4K UHD display that faithfully reproduces surgical images.

• 58-inch LCD monitor with 4K UHD (3840 x 2160 pixels) resolution
• Picture reproduction without delay and flicker
• DisplayPort 1.2 for easy connection
• 12G-SDI (BNC) for long-distance connectivity
• High IP rating ideal for maintaining a sterilized operating room environment

By utilizing PDS0800-HD, signals coming from LMM56800 or LMM0802 are repeated and doubled to connect two 8 megapixel monitors. The HD output generates a downscaled representation of the content displayed on the large screen.

A 26-inch wide screen surgical monitor with full HD display and three screen support.

• 26-inch LCD monitor with full HD resolution (1920 x 1080 pixels)
• Powerful LED backlight with 700 cd/m² luminance for optimal viewing in bright operating rooms
• Smart Resolution with Sparse Coding (S.R.S.C.) for high definition images
• Up to three video sources can be displayed simultaneously
• High IP rating and fanless design ideal for maintaining a sterilized OR environment
